Products Description

Material: PE or PVDF coated 3003 or 3004 Al alloy coil

Single color aluminum alloy wall panel refers to a type of wall panel made of aluminum alloy material with a single color coating on the surface. The single color coating can be customized according to the requirements of the project or the customer, providing a smooth and uniform appearance to the building's exterior.

Single color aluminum alloy wall panel is a type of building material that is used in the construction industry. It is made up of high-quality aluminum alloy material that undergoes a special surface treatment to make the panel appear in a single color. This process helps to make the panel not only aesthetically pleasing but also durable and resistant to wear and tear.

This is a popular material for building facades, curtain walls, and interior wall cladding. The panels come in different sizes, thicknesses, and colors to meet different building design needs. The panels can be cut to size, drilled, bent, and shaped according to the architectural specifications.

The single color aluminum alloy wall panel is ideal for modern architectural designs. The panels have a sleek, elegant, and classic look that enhances the building's overall aesthetic appeal. The panels are also lightweight, making them easy to install, which saves on labor costs and time.

One of the critical features is their ability to resist weathering and fading. The panels are resistant to UV rays, extreme temperatures, and moisture. This makes them ideal for use in different environmental conditions and ensures they maintain their color and quality for extended periods.

Another feature is that it is easy to maintain. The panels are non-corrosive, non-toxic, and non-combustible, making them a safe and low-maintenance alternative to other building materials. They only require occasional cleaning, which can be done easily and quickly by washing with a mild detergent and water.

single color aluminum alloy wall panel is a versatile and durable building material that offers both aesthetic and functional benefits. It is ideal for modern building designs and is easy to install, maintain, and clean. Its excellent resistance to weathering and fading makes it a popular choice for building facades, curtain walls, and interior wall cladding.

202305301313579bd7109bdcdb4dfcbf72caa6b1dc8835

Products parameters

PE Single Color Aluminum Alloy Wall Panelsheet
Parameter
Painting coating	Top:15~18μm Back:5μm
Color	According to customer request
Glossiness	Standard: 35+1-5
Cross-cut adhesion	The paint film does not fall off
T-bend test	3T- the paint film does not fall off
Reverse impact	9J -the paint film does not fall off
MEK test	Butanone MEK wiped back and forth 100 times without damage to the paint film
Heat and humidity resistance	Placed in the non-condensing damp heat test chamber for 1000 hours, no bubbles, cracks, peeling off of the paint film, no change in color, gloss and hardness
Acid and alkali resistance	Soaked in 5% hydrochloric acid for 24 hours, no obvious change in appearance Soaked in 5% sodium oxide for 24 hours, no obvious change in appearance
Neutral salt spray resistance	Neutral salt spray test for 1000 hours
UV lamp accelerated aging test	OUVA-340 UV lamp test box 2000 hours of light, no bubbles, cracks and other defects.

PVDF Single Color Aluminum Alloy Wall Panel sheet
Parameter
Painting coating	Top:20μm Back:5μm
Color	According to customer request
Glossiness	Standard: 25+1-5
Cross-cut adhesion	The paint film does not fall off
T-bend test	1T- the paint film does not fall off
Reverse impact	9J -the paint film does not fall off
MEK test	Butanone MEK wiped back and forth 100 times without damage to the paint film
Heat and humidity resistance	Placed in the non-condensing damp heat test chamber for 1000 hours, no bubbles, cracks, peeling off of the paint film, no change in color, gloss and hardness
Acid and alkali resistance	Soaked in 5% hydrochloric acid for 24 hours, no obvious change in appearance Soaked in 5% sodium oxide for 24 hours, no obvious change in appearance
Neutral salt spray resistance	Neutral salt spray test for 1000 hours
UV lamp accelerated aging test	OUVA-340 UV lamp test box 2000 hours of light, no bubbles, cracks and other defects.
